Model | CGFD8-8-4 | CGFD12-12-5/6 | CGFD18-18-6 | CGFD24-24-8 |
Application | Soda water , sparkling water , Govas, cola etc ...carbonated drink | |||
Production capacity (500ml) | 800~1000 | 2000 | 4000 | 8000 |
Suitable bottle specification | Volume=100-2000ml Diameter φ=50-100 Bottle height H=150 ~340mm | Volume=100-2500ml Diameter φ=50-108 Bottle height H=150 ~350mm | ||
Bottle type | Plastic bottle / PET Bottle | |||
Motor power(kw) | Main motor 1.9kw | Main motor 3.5kw | Main motor 4.0kw | Main motor 4.8kw |
Features | No Bottle No Filling ; No Bottle No Capping | |||
Overall dimensions (mm) | 1900*1420*2000 | 2050*1800*2400 | 2580*2100*2200 | 2780*2200*2200 |
Weight (kg) | 1500 | 2500 | 3500 | 4500 |
| ||||
Model | CGFD32-32-10 | CGFD40-40-10/12 | CGFD50-50-12/15 | CGFD60-60-15 |
Application | Soda water , sparkling water , Govas, cola etc ...carbonated drink | |||
Production capacity (500ml) | 10000 | 12000~13000 | 15000~16000 | 22000-24000 |
Suitable bottle specification | Volume=100-2000ml Diameter φ=50-108 Bottle height H=150 ~340mm | |||
Motor power(kw) | Main motor 7.6kw | Main motor 8.3kw | Main motor 9.6kw | Main motor 15Kw |
Features | No Bottle No Filling ; No Bottle No Capping | |||
Overall dimensions (mm) | 3800*2800*2600 | 4600*2800*2600 | 5450*3300*2600 | 6500*4500*2600 |
Weight (kg) | 6500 | 8500 | 9800 | 12800 |
With years of carbonated soft drink filling experience, we continue to lead the industry with more than 1,00 proven NAVAN Machine Hot Fill solutions worldwide. Over the last thirty years, we have significantly reduced the weight of PET bottles while retaining their durability and improving design opportunities.
1 - Package design , workshop design , produciton design ...
2 - More customisation and design freedom
3 - Improved hygiene and efficiency
4 - Full process control with fewer operators.
