Item | Unit | Model | |||
NF4T100Q | NF4T150Q | NF4T200Q | NF6T300Q | ||
Capacity | Cans/min | ≤100 | ≤150 | ≤200 | ≤300 |
CAN Diameter | mm | Φ53~66 | Φ53~66 | Φ53~66 | Φ53~66 |
CAN Height | mm | 80~175 | 80~175 | 80~175 | 80~175 |
Filling unit | Unit | 12 | 20 | 24 | 32 |
Sealing unit | Unit | 4 | 4 | 4 | 6 |
Power | Kw | 7.5 | 7.5+0.37 | 7.5+0.55 | 7.5+0.75 |
Weight | T | 3.5 | 4.5 | 4.5 | 7.5 |
Dimension | mm | 2800×1500×2000 | 3100×1850×2000 | 3250×2050×2000 | 3800×2300×2000 |
With years of CAN filling sealing experience, we continue to lead the industry with more than 1,00 proven NAVAN Machine Hot Fill solutions worldwide. Over the last thirty years, we have significantly imporve the filling sealing precision of CAN while retaining their durability and improving design opportunities.
1 - Package design , workshop design , produciton design ...
2 - More customisation and design freedom
3 - Improved hygiene and efficiency
4 - Full process control with fewer operators.
